Pneumatic rotary joint
FUXUAN
| Place of Origin | Shandong, China |
| Customized support | OEM, ODM |
| Brand Name | Shandong Focus Machinery Co., Ltd. |
| Product name | multipath rotary joint |
| Size | 2 to 24 |
| Max.Speed | 500RPM |
| Max. Pressure | 40bar |
| Max. Temperature | -18-105℃ |
| Applicable medium | GAS,AIR |
The LT Series multiport pneumatic rotary unions are available with 2, 4, 8, 12 and 24 passages. They are designed for use with air, gas and vacuum and are ideal for many automation and robotic applications. These lightweight and compact rotary joints feature aluminum construction and independent flow passages that can transfer different types of media simultaneously. All models in this rotary union series come standard with threaded connections on the radial sides of the shaft and housing. The models are also available with axial O-ring face seal glands (version OF) on the rotor side for flush mounting on an interface. You can easily combine these multiport unions with electrical power and/or data signals. They are designed to easily integrate our miniature and Ethernet slip rings.
| Place of Origin | Shandong, China |
| Customized support | OEM, ODM |
| Brand Name | Shandong Focus Machinery Co., Ltd. |
| Product name | multipath rotary joint |
| Size | 2 to 24 |
| Max.Speed | 500RPM |
| Max. Pressure | 40bar |
| Max. Temperature | -18-105℃ |
| Applicable medium | GAS,AIR |
The LT Series multiport pneumatic rotary unions are available with 2, 4, 8, 12 and 24 passages. They are designed for use with air, gas and vacuum and are ideal for many automation and robotic applications. These lightweight and compact rotary joints feature aluminum construction and independent flow passages that can transfer different types of media simultaneously. All models in this rotary union series come standard with threaded connections on the radial sides of the shaft and housing. The models are also available with axial O-ring face seal glands (version OF) on the rotor side for flush mounting on an interface. You can easily combine these multiport unions with electrical power and/or data signals. They are designed to easily integrate our miniature and Ethernet slip rings.
